The Garrett PowerMax Stage 1 GT2260S is a direct-fit turbocharger upgrade for VAG 2.0 TSI/TFSI EA888 EVO4 engines. This complete turbocharger with electronic actuator maintains the OEM installation and delivers up to 447 hp (flywheel), based on on-vehicle test results. Thanks to GTX Gen II compressor aerodynamics, this turbocharger offers significantly more flow and efficiency than the standard turbocharger.
Advantages
• Direct-fit Stage 1 upgrade with OEM fit
• Up to 447 hp power capacity
• +32% more compressor flow compared to OEM Golf 8 GTI turbo
• High thermal load capacity up to 1050°C
• Fully assembled with electronic actuator
• Improved airflow and efficiency
• Suitable for street and performance builds
Technical specifications
• Turbo type: Garrett PowerMax Stage 1 GT2260S
• Maximum power: up to 447 HP (333 kW, flywheel)
• Bearing: Latest generation journal bearing rotor group
• Thrust bearing: 360° reinforced
• Compressor wheel: GTX GEN 2 aerodynamics
• Turbine wheel: Mar-M alloy, heat resistant up to 1050°C
• Turbine housing: Twin-scroll stainless steel, up to 1050°C
• Compressor housing: High-flow with speed sensor port
• Water connections: 4
• Maximum turbo speed Stage 1: 186,000 rpm
Dimensions
Compressor
• Inlet: 47.00 mm
• Exhaust: 60.00 mm
• Trim: 62
Turbine
• Inlet: 50.00 mm
• Exhaust: 45.00 mm
• Trim: 81
Compatibility
• Audi Q3 45 TFSI 2.0 2021+
• Audi TT 45 TFSI 2.0 2020+
• Cupra Leon 2.0 TSI 2021+
• Cupra Formentor 2.0 TSI 2021+
• Seat Tarraco 2.0 TSI 2021+
• Skoda Kodiaq RS TSI 4x4 2021+
• Skoda Octavia RS 2020+
• VW Tiguan 2.0 TSI 2020+
• VW Golf 8 GTI 2020+
Contents
• Garrett PowerMax Stage 1 GT2260S turbocharger
• Calibrated electronic actuator
• Machined speed sensor port in compressor housing
• Please note: speed sensor kits/modules are sold separately
Frequently Asked Questions
Is this a bolt-on upgrade?
Yes, this turbo is designed as a direct replacement for the OEM turbo.
Is tuning necessary?
Yes, custom ECU software is required to safely utilize maximum power.
Is a speed sensor included?
No. Compatible speed sensors (sold separately):
• 781328-0003 (sensor + display)
• 781328-0004 (sensor only)
What is the maximum allowed turbo speed?
186,000 rpm - Use above this limit is at your own risk and may cause damage or premature wear.
