Airtec Motorsport intercooler upgrade for the 1 and 3 Series diesel models. Suitable for track use or highway driving.
To ensure no noticeable loss of performance during long, intense drives, they developed a larger, freer-flowing intercooler that's a direct replacement for the smaller, more restrictive OEM part.
The solution to increasing the intercooler's size and performance within the limited space behind the bumper is based on a wider, taller core with a massive 150mm depth. This offers a massive 94% increase in total capacity compared to the original intercooler, as well as a significant increase in frontal area, allowing it to optimally utilize the airflow.
In addition to the powder-coated intercooler, the package also comes with all mounting hardware and detailed mounting instructions.
Its massive cooling capacity makes it an essential modification for modified X1, 1 and 3 Series diesel models.
• 94% increase in total capacity compared to original
• Cast end tanks for improved airflow and strength
• Increase in frontal area compared to standard
• Huge increase in cooling capacity
• Black powder coated finish
• Includes mounting hardware
• Airtec logo at no extra cost
OEM dimensions:
Width: 520mm
Height: 100mm
Depth: 90mm
Capacity: 4.7 liters
Front surface: 5,200 cm²
Airtec dimensions:
Width: 550mm
Height: 110mm
Depth: 150mm
Capacity: 9.1 litres
Front surface: 6,050 cm²
Inlet and outlet diameter: 62 mm
This intercooler is a replacement for BMW part number 17517524916 and is suitable for all models with matching 62mm inlet and outlet diameters.
NOTE:
Only fits the N47 and M47 engines.
If your car has 70mm intakes and exhausts, you'll need this intercooler:
Airtec Motorsport Intercooler Upgrade for BMW E9x 325d/330d/335d (E-Series) - Airtec Motorsport
If you are unsure, measure the inlet and outlet diameters or check the part number of your current intercooler by entering your car's VIN number into the BMW Parts Catalog (realoem.com).
Contents:
• Intercooler
• Mounting material
